Product introduction

Mesh belt conveyor line is also known as mesh belt conveyor. Mesh belt conveyor line is a material handling machine that continuously transmits materials on a certain line, also known as continuous conveyor, which can be divided into mesh belt type and mesh chain type. The conveyor can carry out horizontal, inclined and vertical transmission, and can also form a spatial transmission line, which is generally fixed. The conveying capacity of the conveyor is large, the transport distance is long, and several process operations can be completed at the same time in the conveying process, so it is widely used.

Product characteristics

The mesh belt conveyor is an important conveyor belt in the assembly line equipment, which has the characteristics of smooth surface and uniform distribution of through holes. Driven by the conveyor chain, the production operation and transportation process becomes stable, and when transporting materials, it has the characteristics of strong carrying capacity and high tensile strength

Product highlights

1, excellent sealing

2, simple structure, strong stability

3, small cross-sectional area, can effectively save space

4, flexible flow, reduce manual intervention

1. Conveying capacity: The conveying capacity of the conveyor refers to the amount of material transported per unit time. When conveying bulk materials, the mass or volume of the material transported per hour is calculated; When conveying a piece, it is calculated as the number of pieces transported per hour.

2. Conveying speed: Improving conveying speed can improve conveying capacity. When the conveyor belt is used as the traction part and the conveying length is large, the conveying speed increases day by day. However, high-speed belt conveyors need to pay attention to vibration, noise and starting, braking and other problems. For the conveyor with the chain as the traction part, the conveying speed should not be too large to prevent increasing the dynamic load. At the same time for the process control of the conveyor, the conveying speed should be determined according to the production process.

3. Component size: the component size of the conveyor includes conveyor belt width, slat width, hopper volume, pipe diameter and container size. The size of these components directly affects the conveying capacity of the conveyor.

4. Conveying length and inclination Angle: conveying line length and inclination directly affect the total resistance of the conveyor and the required power.
